FEATURE:
-- High performance, digital multivoltage standard servo
-- High-precision steel gears
-- Full CNC aluminium hulls and structure
-- High quality coreless motor
-- Dual ball bearings
-- Super long working life
SPECIFICATIONS:
Operating Speed(5.0V):0.21sec/60degrees
Operating Speed(6.0V):0.17sec/60degrees
Operating Speed(7.4V):0.14sec/60degrees
Operating Speed(8.4V):0.12sec/60degrees
Stall torque(7.4V):40.0kg.cm(555.60oz/in)
Maximum working torque(7.4V):20.0kg.cm(277.8oz/in)
Rated working torque(5.0V):8.0kg.cm(111.12oz/in)
Rated working torque(6.0V):11.0kg.cm(152.79oz/in)
Rated working torque(7.4V):14.0kg.cm(194.46oz/in)
Rated working torque(8.4V):16.0kg.cm(222.24oz/in)
Dimensions: 40*20*37.3mm /1.56*0.78*1.45in
Weight: 77.7g(2.74oz)
Connector Wire Length: JR300 mm (1.17in)
Optional Accessories:
UAV01-001:Offered accessories
UAV01-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
