FEATURE:
-- High performance programmable digital Multivoltage standard servo
-- High-precision full steel gear
-- Install latest magnetic sensor positioner internally
-- High quality coreless motor
-- Full CNC aluminium hulls and structure
-- Dual ball bearings
-- Waterproof
SPECIFICATIONS:
Operating Speed(5.0V):0.14sec/60degrees
Operating Speed(6.0V):0.12sec/60degrees
Operating Speed(7.4V):0.09sec/60degrees
Operating Speed(8.4V):0.08sec/60degrees
Stall torque(7.4V):42.0kg.cm(583.38oz/in)
Maximum working torque(7.4V):20.0kg.cm(277.80oz/in)
Rated working torque(5.0V):7.0kg.cm(97.23oz/in)
Rated working torque(6.0V):9.0kg.cm(125.01oz/in)
Rated working torque(7.4V):11.0kg.cm(152.79oz/in)
Rated working torque(8.4V):14.0kg.cm(194.46oz/in)
Dimensions:40*20*37.4mm/1.56X0.78X1.45in
Weight:80g(2.82oz)
Connector Wire Length:JR300mm(11.7in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 127g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:13.2kg
Optional Accessories:
CLS4211S-001:Offered accessories
CLS4211S-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
